Layer: 2022 Impervious Surface (ID: 3)

Name: 2022 Impervious Surface

Display Field: CLASS

Type: Raster Layer

Geometry Type: null

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This map was derived from a 12-class land-cover product developed for the Chesapeake Bay Watershed. It was extracted from a map showing land-cover conversion in the Chesapeake Bay Watershed during the period 2017/2018-2021/2022. The change-detection map was modeled with an existing 2017/2018 (Time Period 2, or T2) land-cover map containing the following classes: Water, Emergent Wetlands, Tree Canopy, Scrub\Shrub, Low Vegetation, Barren, Impervious Structures, Other Impervious, Impervious Roads, Tree Canopy Over Impervious Structures, Tree Canopy Over Other Impervious, and Tree Canopy Over Impervious Roads. Using object-based image analysis mapping techniques, the T2 map was first refined, where necessary, using all remote-sensing imagery and GIS datasets available for 2021\2022, including LiDAR, multispectral imagery, and thematic layers (e.g., roads, building footprints). The refined T2 map was then compared to imagery and GIS data corresponding to the period 2021/2022 (Time Period 3, or T3), identifying features that had changed during the analysis interval. Each change combination was assigned to a unique category that indicated both the "from" and "to" classes, enabling monitoring of specific types of change. Features that had not changed during the analysis interval were also incorporated into the change map, making it possible to reconstitute full land cover for either T2 or T3. Draft output was manually reviewed and edited to eliminate obvious errors of omission and commission, focusing on the most important types of landscape change: 1) tree-canopy loss; and 2) impervious-surfaces gain. The final map contained 79 change classes plus the original 12 classes for features that had not changed. The specific analysis periods for the watershed's 7 states\districts were: Delaware, 2018-2021; District of Columbia, 2017-2021; Maryland, 2018-2021; New York, 2017-2022; Pennsylvania, 2017-2022; Virginia, 2018-2021; and West Virginia, 2018-2022. The 12-class extract of the change-detection map was created by reassigning all change classes to their T3 status.</SPAN></P><P><SPAN>For specific use in land-use\land-cover (LULC) analyses for Delaware, the T3 map produced for the Chesapeake Bay Watershed was reclassifed into two classes: Impervious (1); and Pervious (2). It was reviewed and edited against 2022 leaf-off imagery to update it to 2022 conditions. </SPAN></P><P><SPAN>This map was based on a draft version of Chesapeake Bay Watershed land cover. A publicly-available version of the final Chesapeake Bay map will be available in autumn 2024, through the Chesapeake Conservancy (https://www.chesapeakeconservancy.org/).</SPAN></P></DIV></DIV></DIV>

Copyright Text: The University of Vermont Spatial Analysis Laboratory developed this map in cooperation with the Chesapeake Conservancy and the U.S. Geological Survey.

Default Visibility: true

MaxRecordCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

Drawing Info:

N/A Advanced Query Capabilities:

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
VALUE ( type: esriFieldTypeInteger, alias: VALUE )
COUNT ( type: esriFieldTypeDouble, alias: COUNT )
CLASS ( type: esriFieldTypeString, alias: CLASS, length: 254 )

Supported Operations: Query Query Attachments Query Analytic Generate Renderer Return Updates
